In real-world implementation, “Vietnam Cleanroom equipment VCR” observes that lithium battery cleanrooms are often misunderstood as standard electronics cleanrooms. The key difference is that lithium battery production is extremely sensitive to moisture rather than just particles. While semiconductor cleanrooms focus primarily on particle control, lithium battery environments prioritize humidity control above all else. Even a small amount of moisture can react with electrolyte, generate gases, degrade performance, or create safety risks. Therefore, lithium battery cleanrooms are essentially high-performance dry rooms combined with particle control systems.

Nature of lithium battery manufacturing and environmental sensitivity

Lithium-ion battery production includes electrode coating, calendering, slitting, stacking/winding, and electrolyte filling. The electrolyte is highly sensitive to water. Moisture can react to form hydrofluoric acid (HF), causing corrosion and reducing battery life. Therefore, controlling humidity is critical. Particle contamination is also important, as it can cause internal short circuits, but it is generally secondary to moisture control.

Humidity and dew point – the most critical parameter

The most important requirement is maintaining extremely low humidity. Instead of relative humidity (RH), dew point is used for precise measurement of moisture content. Critical areas such as electrolyte filling typically require dew points between -30°C and -50°C or even lower. This corresponds to extremely dry air conditions. Failure to meet these requirements can compromise the entire production process.

Dry room vs traditional cleanroom

Lithium battery production environments are often referred to as dry rooms rather than standard cleanrooms. Dry rooms focus on removing moisture using desiccant dehumidification systems, while traditional cleanrooms focus on particle filtration. In practice, both functions are combined, but humidity control is always the top priority.

ISO class requirements

Lithium battery cleanrooms typically do not require ultra-low ISO classes. ISO Class 7–8 is sufficient for most areas. In critical processes, ISO Class 6 may be used to reduce the risk of particle-induced short circuits. Stability is more important than achieving extremely low particle counts.

Particle contamination and short circuit risk

Particles can cause internal short circuits if they become trapped between electrodes. This can lead to defective cells or safety hazards. Therefore, particle control through HEPA filtration and proper airflow design is still essential, even if not as stringent as semiconductor environments.

Temperature control

Temperature is usually maintained between 20–25°C. It affects slurry viscosity, chemical reaction rates, and equipment performance. Temperature also influences the efficiency of dehumidification systems.

Airflow design in dry rooms

Turbulent airflow is typically used to distribute dry air evenly and avoid dead zones. Laminar flow is not usually required. However, airflow must prevent moisture infiltration from surrounding areas.

Differential pressure and airtightness

Positive pressure is maintained to prevent humid air from entering the dry room. Airtight construction is critical, as even small leaks can increase moisture levels and disrupt dew point conditions.

Explosion and fire safety requirements

Lithium battery production involves flammable solvents and chemicals. Therefore, cleanrooms must include explosion-proof design (ATEX compliance), proper ventilation, and gas monitoring systems. This is a key requirement that distinguishes lithium battery facilities from many other cleanrooms.

HVAC and dehumidification systems

HVAC systems must integrate high-capacity desiccant dehumidification units. These systems consume significant energy to maintain low dew points. Proper design is required to balance performance and energy efficiency.

Monitoring – focus on dew point

Monitoring systems prioritize continuous dew point measurement rather than RH. Additional parameters include temperature, pressure, and particle levels. Continuous monitoring is essential to maintain process stability.

Common design mistakes

A common mistake is treating lithium battery facilities as standard cleanrooms without prioritizing humidity control. Poor airtightness and insufficient dehumidification capacity are also frequent issues.

Impact on yield and safety

High humidity can reduce battery lifespan, cause defects, or create safety risks such as thermal runaway. Particle contamination can lead to short circuits. Environmental control directly affects both product quality and safety.

Effective design approach

Design should start with required dew point levels. Then, a high-performance dry room system with excellent airtightness should be implemented, combined with particle filtration. Monitoring and BMS integration ensure long-term stability.

Conclusion: What are the special requirements for lithium battery cleanrooms?

The key requirement is extremely low humidity (dew point -30°C to -50°C), combined with particle control and explosion safety. This is a unique environment where “dryness” is more critical than “cleanliness.”
